ONKA 150mm2 M12 screw rail connector DIN rail connector, with protective cover, gray, 1030088

M12, 150mm2, threaded rail connector / DIN rail connector with protective cover, gray, ONKA, made in Turkey.

ONKA's compact mounting rail connectors offer excellent possibilities for connecting any wires with different cross-sections. Thanks to the transparent housing, it is easy to check the correct arrangement of the wires. Original ONKA quick connectors facilitate installation and guarantee 100% connection reliability.

Technical parameters

Maximum cross-section of a single wire to be connected: 150mm2
Color: gray
Main housing insulation material: polyamide (PA6.6).
Contact/bridge material: CK45 steel/copper
Switching position: lateral / lateral
Rated voltage: 1000V
Rated current: 309A
Operating temperature range: -40°C
Maximum operating temperature range: 140°C
Mounting method: DIN 35 mm mounting rail
